This motor driver for DC and stepper motors is highly regarded due to its use of the renowned L298N Dual H Bridge Driver Chip. It is designed for optimal performance at an affordable price.
The L298N Dual H Bridge DC/Stepper Motor Driver Controller Module is capable of driving two robot motors. It utilizes the well-known L298N Dual H-Bridge Motor Driver chip, offering the power to drive motors ranging from 5 to 35 volts at up to 2 amps per channel. The versatile digital input controls enable each motor to operate independently, providing complete control over speed, direction, and braking.
This board also includes a convenient 5V regulator that can power additional components, such as your robot's microcontroller. Its modular design is easily adaptable to various robot controllers, including the popular Arduino series.
This L298N driver module features a brand new original L298N chip from STMicroelectronics. It employs surface-mount technology (SMT) and high-quality aluminum electrolytic capacitors to stabilize the circuit. The module allows for easy control of DC motor speed and direction, as well as control of two-phase stepper motors.
1 x L298N Dual H Bridge DC Stepper Motor Driver Controller Module
| Driver IC |
L298N |
| Input Supply Voltage (VDC) |
5 ~ 35 |
| Supply Current (A) |
2 (peak per channel) |
| Logic Voltage (V) |
4.5 to 5.5 |
| Logic Current (mA) |
0 to 36 |
| Control signal input voltage (V) |
4.5 to 5.5 |
| Maximum Power (W) |
20 |
| Operating Temperature (C) |
-25 to 130 |
| Length (mm) |
55 |
| Width (mm) |
60 |
| Height (mm) |
30 |
| Weight (gm) |
35 |
* Product Images are shown for illustrative purposes only and may differ from actual product.
